Model.BL260 MINI BRUSHLESS ELECTRIC WINCH

capacity: 260kg

Electric winch built for structural members, curtain-wall glass, advertising boards and other materials handled during storage or freight transportation.

Compact structure, high efficiency, light weight, a power supply that asks for nothing special, and cost saving. Five things this unit delivers at once.

Item	Specification
Model	BL260
Voltage/frequency	220V 50/60Hz
Speed	7-19m/min
Wire rope	30m (5mm × 30m)
Motor	2100W
Rated Load	260kg
Net weight	17kg

Model.BL260 Mini Brushless Electric Winch is a 260kg single-phase electric winch built for structural members, curtain-wall glass, advertising boards and other materials handled during storage or freight transportation. It weighs 17kg, runs on 220V 50/60Hz and offers a lifting speed from 7 to 19m/min on a 30m wire rope. GOODIDEA lists it in its Brushless Mini Electric winch category, and this article covers what the unit delivers, how it is protected and where it sits in the brushless line.

Five Things the BL260 Delivers at Once

The product page from GOODIDEA sums up the BL260 in five points, and each one matters on a working site.

Compact structure

the whole unit stays compact, with motor and gearbox sharing one housing.

High efficiency

high power and high efficiency allow long time working shift after shift.

Light weight

17kg net weight against a 260kg rated load.

Ordinary power supply

a power supply that asks for nothing special, with 110V or 220V single phase offered.

Cost saving

the compact, efficient design is described as cost saving.

BL260 Specifications

Item	Specification
Model	BL260
Voltage/frequency	220V 50/60Hz
Speed	7-19m/min
Wire rope	30m (5mm x 30m)
Motor	2100W
Rated Load	260kg
Net weight	17kg

A 7 to 19m/min Speed Range on 2100W

The BL260 does not run at one fixed pace. Its speed is listed as 7-19m/min, and stepless speed regulation sets the pace, so an operator can slow down for delicate positioning and speed up for open travel. The 2100W motor lifts a 260kg rating on a 17kg machine, a ratio of about 15.3 to 1, which is why GOODIDEA presents the unit as light for its capacity.

Motor System and Electric Control

Power of industrial grade comes from a permanent-magnet brushless motor, and the unit is hard to damage. Either single-phase voltage works, 110V or 220V, and both are offered. A temperature protection device and an overload protection device guard the winding, and the enameled wire is rated for 200 degrees Celsius. Working capacity ends up 50 percent above the ED series.

The circuit is capacitor-free by design and answers to SCM control, which gives stable performance and a high power factor. Plug and pull wiring keeps day-to-day operation convenient and maintenance reliable, a point GOODIDEA stresses for crews that relocate the winch often.

Brake System and Limit Switch

Dual braking is the arrangement, with mechanical ratchet braking on one side and resistive short-circuit control on the other. Sintered brake material of high friction coefficient gives the motor its durability. When power is cut or a winch failure occurs, braking is immediate, so high safety and long service life follow.

The limit switch guards the travel. Once the hook reaches a certain lifting height, or the wire rope is reversed, it triggers, protects the machine and stops it working.

Cable, Gear and Housing

Component	What is stated
Cable	Top brand imported wire rope, safety factor 4 times that of ordinary machines
Gear system	High efficiency bevel drive reduction gear with special heat treatment, strength three times higher than ordinary products
Main unit housing	One-piece aluminum alloy die-casting structure of strong toughness housing both motor and gearbox
Machining	High precision CNC machining for smooth running and low noise
Finish	Automobile grade powder coating for a nice appearance

Where the BL260 Sits in the Brushless Line

The Brushless Mini Electric winch category at GOODIDEA lists four single-capacity models: BL170 at 170kg, BL260 at 260kg, BL340 at 340kg and BL490 at 490kg. The BL260 is the second step in that ladder, 90kg above the BL170 and 80kg below the BL340, so it suits buyers whose heaviest load falls between 170kg and 260kg.

Model	Capacity
BL170	170kg
BL260	260kg
BL340	340kg
BL490	490kg

Frequently Asked Questions

QWhat speed range does the BL260 offer?

The speed is listed as 7-19m/min, with stepless speed regulation.

QHow much does the BL260 weigh compared with its rated load?

The net weight is 17kg and the rated load is 260kg, a ratio of about 15.3 to 1.

QWhat motor power does the BL260 use?

The motor is rated at 2100W and is a permanent-magnet brushless motor.

QDoes the BL260 need a capacitor?

No. The circuit is capacitor-free and uses SCM control.

QWhat protects the motor winding?

A temperature protection device and an overload protection device guard the winding, and the enameled wire is rated for 200 degrees Celsius.

QHow long is the wire rope on the BL260?

The wire rope is 30m long and 5mm in diameter.

QWhich brushless winch capacities are listed besides 260kg?

The category also lists the BL170 at 170kg, the BL340 at 340kg and the BL490 at 490kg.

QCan the BL260 be supplied with OEM service?

GOODIDEA states that it supplies its brushless winches with OEM and custom service for your brand.

Final Word

The BL260 gives buyers a 260kg brushless winch at 17kg, with a 7-19m/min speed range, dual braking and a limit switch. For orders, brand projects or capacity questions, buyers can take these specifications to GOODIDEA.
